CP4400 - Bulkhead Mounted Master Cylinder

A compact forged bodied flanged master cylinder suitable for all brake and clutch applications especially where space is restricted.

Features:

• Cast Aluminium Alloy Body
• Extra travel to cut-off
• 'Centre Lock' Bulkhead fixing
• 10 Available bore sizes
• Hydraulic threads are imperial.

Technical Details

• Weight: 0.29 KG
• Full Stroke: 25.4mm (1.00")
• Travel to Cut-off: 0.48 to 0.63mm (0.019" to 0.025")
• Hydraulic Threads:
• Outlet: 3/8" x 24 UNF
• Inlet: 7/16" x 20 UNF
• Push Rod Threads:
• PRT: 5/16" UNF
• PRM: M8 x 1.25
• Push Rod Length from Mounting Flange:
• PRT/PRM135: 135mm (5.31")
• PRT/PRM180: 180mm (7.08")

Repair Kits

Each repair kit is in accordance to Bore Diameter of Master Cylinder:

• Ø14.00mm Bore - CP2623-88RK
• Ø15.00mm Bore - CP2623-89RK
• Ø15.90mm Bore - CP2623-90RK
• Ø16.80mm Bore - CP2623-905RK
• Ø17.80mm Bore - CP2623-91RK
• Ø19.10mm Bore - CP2623-92RK
• Ø20.60mm Bore - CP2623-93RK
• Ø22.20mm Bore - CP2623-94RK
• Ø23.80mm Bore - CP2623-95RK
• Ø25.40mm Bore - CP2623-96RK
